AGM Global Vision Rattler TC35-640
AGM Global Vision Rattler TC35-640
The Rattler TC is a compact thermal imaging clip-on system that allows quick transformation of the day optics into thermal imaging device without any special tools or equipment.
Rattler TC has a high-sensitivity thermal detector and 1024×768 OLED monitor, which provides a clear image under harsh environmental conditions like darkness, fog, smoke, dust, rain, snow, wood, camouflage, etc. The product is mainly applied to scenarios such as patrolling, hunting, overwatch, etc.
The Rattler TC can easily be attached in front of rifle scopes with magnification up to 8x for medium range use.
Powered with two CR123 batteries the AGM Rattler TC gives up to 4.5 hours of continuous operation time. The device is equipped with 16 GB storage for on-board video recording and image capturing.
Onboard Wi-Fi module is also available for live video streaming and video/images recording via mobile application.
Warning: California's Proposition 65
- Quick conversion of daytime optics into thermal imaging scope
- 12μm high sensitivity detector (NETD <35mK)
- 640×512 thermal resolution
- 1024x768 resolution 0.39-inch OLED display
- Video recording and snapshot, built-in EMMC (16 GB)
- Supports distance measurement
- Adjustable color palettes
- Wi-Fi data transmission
- Waterproof, shockproof
- Up to 4.5 hours continuous working
- External power supply capability
- 5-Year warranty
- Detector type: 12 μm VOx Uncooled Focal Plane Arrays
- Refresh rate: 50 Hz
- Resolution: 640x512
- USB Cable
- Lens Tissue
- User Manual
- Carrying Case
- CR 123 Batteries
- Day Scope Adapter with Inserts
Specifications:
| Shock and vibration | 750 g/ms |
| Detector type | 17μm, Uncooled, 50Hz |
| Standby Mode | Yes |
| Resolution | 640x512 |
| Detection Range (6' object) | 1750m/yd |
| Snapshot | Yes |
| Lens system | 35 mm; F/1.0 |
| Field of view (H × X) | 12.5° × 10.0° |
| Digital zoom | 2x, 4x, 8x |
| Imaging palettes | Jungle, Recognition |
| Display | Yes |
| Storage | Built-in EMMC (16 GB) |
| Video/Photo Format | Yes |
| Battery Type | Two CR123A (3V) Lithium or two RCR123 (up to 4.2V) Rechargeable Batteries |
| Wi-Fi | Yes |
| Battery Life (Operating) | Up to 4.5 hr |
| External power supply | 5V USB |
| Operating Temperature Range | -20°C to +55°C (-4°F to +131°F) |
| Degree of Protection | IP67 |
| Weight | 0.42 kg (0.93 lb) |
| Overall Dimensions | 153 mm × 62 mm × 59 mm (6.0 × 2.4 × 2.3 in) |
| Magnification | 1x |
